F6217 HIMA 8-channel analog input module

INQUIRE NOW

Products Name: F6217 HIMA 8-channel analog input module

PRODUCT DESCRIPTION

Brand：HIMA

Model number：F6217

Colour：new

Warranty: 12 months

Lead Time：3-day working day

Country of origin: USA Price: Please contact us

Product weight：0.46kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

Notes to the safety-related operation and useScreened cables have to be used for the field input circuits, twisted cables are recommendedif it is sure that the environment of the transmitter up to the module is free from interferencesand the distance is relatively short (e. g. inside a cabinet) then the cabling can be performedwithout screened cables or twisted cables. However, the interference immunity of the analoginputs can only be achieved by using screened cables.

Planning notes for ELOP IlFor each input channel of the module exists an analog input value and an appertaining channefault bit. With activated channel fault bit a safety-related reaction has to be programmed inELOP Il related to the corresponding analog input.

Recommendations for the use of the module according to IEC 61508, SIL 3Cables for power supply shall be locally separated from the input circuits,Application of a suitable earthing must be regarded,Measures against rising of the temperature have to be taken outside of the module, e. gfans in the cabinet.

Recording events in a logbook for operation and maintenance.

A maintenance of the module is not required. ln case of fault there is a switch-off. The failedmodule must be replaced.

Z 7128 Cable plug with transmitter supplyFor the supply of transmiters the Z 7128 cable plug with transmitter supply is available (suita.ble only for two-wire connections).
