10024/F/F Honeywell Controller module Brand new

Series-C I/O modules are constructed to support normal field failures, wiring errors and conditions such as a shorted wire. All Series-C IOTAs contain at least one fuse that provides protection for catastrophic errors in the IOTA, IOM and other elements of the Series-C system. In normal operation as well as many abnormal operations, the fuse element should not blow.

INQUIRE NOW

Products Name: 10024/F/F Honeywell Controller module Brand new

PRODUCT DESCRIPTION

Brand:   Honeywell

Model number:10024/F/F

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.5kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service Professional Sales provides 24 hours /7 days online service

10024/F/F   Honeywell   Controller module Brand new

Description:

Green IOM is powered.

Status

LED

Off There is an IOM fault or the LED is bad.

The module is in a hard failure state. In this state, the module cannot be

used to gather information from or send information to attached field

devices.

ACTION: A user must either cycle power to the module or replace the

module to correct the failure.

Green IOM operation is Okay.

Primary Run/Idle

The module is operating 100% correctly, and the module if commanded;

will either gather inputs from the attached field devices or send outputs to

the attached field devices.

NOTE

When used in a redundant I/O system, a module with a green

LED is often referred to as the primary I/O module.

Green -

flashing

(toggle once

per second)

Primary Run/Idle with Soft Failure

The module is operating, but it is operating in a diminished state as one or

more soft failures have been identified.

Amber The module is either not configured or operating as a secondary.

Not Configured - The module has not been configured.

Secondary - The module is operating 100% correctly as the secondary

module. This does not imply that it is synchronized with the primary IOM.

Amber -

flashing

(toggle once

per second)

Not Configured with Soft Failure - The module has not been configured

and is operating with one or more active soft failures.

Secondary with Soft Failure- The module is operating as the secondary

module in a diminished state as one or more soft failures have been

identified.

Red Power-on - The device is in a non-standard, transient state and not

controlling any part of your plant or process.

Module has just started and power-on self-test is running. During this time,

there is no communication to the module.

Red - flashing

(toggle once

per second)

The device is in a non-standard, transient state and not controlling any part

of your plant or process.

Alive, Ready for Firmware Upgrade - The module is ready to receive an

update to its internal programming instructions.

Red - fast

flashing,

(toggle one

quarter (1/4)

second)

The device is in a non-standard, transient state and not controlling any part

of your plant or process.

Alive, Firmware Upgrade in Progress - The module is receiving an update to

its internal programming instructions. Do not remove power to the module.

Off Failed - The module has hard failed. The module is no longer

communicating and must be power cycled or replaced.

DO channels transition to the configured fault state. If field power is lost, all

outputs go unpowered.

AO channels will go unpowered.
