Standard 2-wire transmitter l Can use any of the 16 channels.
l No custom wiring required.
l No jumper cuts required.
Standard self-powered
transmitter
l Can use any of the 16 channels.
l No custom wiring required.
l No jumper cuts required.
Self-powered transmitter with
loop power (system ground)
l Can use any of the 16 channels.
l Custom wiring is required for channels 1-12: you must find a
screw terminal at Series C ground for one leg of the
transmitter.
l No jumper cuts required
Self-powered transmitter with
loop power (device ground)
l Cannot use channels 1-12.
l Only use channels 13-16.
Self-powered 3-wire
transmitter
(system ground)
l Can use any of the 16 channels.
l Custom wiring is required for channels 1-12: you must find a
screw terminal at Series C ground for one leg of the
transmitter.
l No jumper cuts required
Voltage Input (system ground) l Can use any of the 16 channels.
l Custom wiring is required for channels 1-12: you must find a
screw terminal at Series C ground for one leg of the
transducer.
l You must cut the jumper associated with the range spool.
Voltage Input (device ground) l Cannot use channels 1-12.
l Only use channels 13-16.
NOTE
If multiple instruments need a ground reference the four positions of TB2 can serve as
those ground points (assuming the JP17-JP20) jumpers are intact. If more than four
grounding screws are needed then a custom wire from TB2 to a separate terminal
block can allow for more grounding screw positions.
