The PUB and PVB controllers are part of the Spyder family.
The nine controllers are BACnet MS/TP network devices
designed to control HVAC equipment. These controllers
provide many options and advanced system features that
allow state-of-the-art commercial building control. Each
controller is programmable and configurable using the
NIAGARA FRAMEWORK
software.
The Spyder BACnet controllers require the Spyder BACnet
Programmable Feature to be licensed in the WEBpro
workbench tool and the WEBS AX JACE Controller for
programming and downloading. The Spyder BACnet Models
are also available as Individually Licensed Controllers (ILC).
The ILC versions are identical in design and capability in
every detail except for the licensing. The Individual
Licensing of the Spyder ILCs (the License is built in) allows
them to be programmed and downloaded with any brand of
the Niagara Workbench or JACE controller. The Spyder ILCs
are identified with a suffix on the Part Number of -ILC.
Example: PUB6438S-ILC follows all the same Installation
Instructions information as the PUB6438S.
The controllers are for use in VAV (Variable Air Volume),
Unitary, and advanced HVAC control applications. Each
controller contains a host microcontroller to run the main
HVAC application and a second microcontroller for
BACnet MS/TP network communications. Each controller
provides flexible, universal inputs for external sensors,
digital inputs, and a combination of analog outputs and
digital outputs.
The photo shown is the PVB6436AS, which includes the
Series 60 floating actuator.
