PM I/O IOC
parameter
Series C I/O
IOC parameter
Change from PM I/O channel/comment
SENSRTP SENSRTP A list of valid values for the particular AI channel type is always
provided. You are NEVER displayed or allowed to select an invalid
value for any particular AI channel type.
Refer to the Control Builder Parameter Reference guide for
parameter specific information.
PVCHAR PVCHAR
PNTTYPE (removed) Parameter is deleted. Some TPS 'FULL' point parameters are now
part of Series C I/O channel blocks.
SLWSRCRCID (removed) Parameter was deleted. SLIDEWIRE sensor type is not supported
Series C I/O. SLIDEWIRE sensor type was not implemented in PM
I/O. However, the parameter was defined.
PVRAWHI PVRAWHI These parameters are valid only for AICHANNELS that exist on AILLMUX IOMs. PVRAWLO PVRAWLO
HPVCHAR PVCHAR The PM I/O functionality provided by setting HPVCHAR to 'Device
Range' is provided by the setting PVCHAR to 'Device Range.'
ACCEPTRNG ACCEPTRNG The text on this push button changed from 'Accept Device Ranges'
to 'Sync. Device and PV Ranges'.
HPVMISM HPVMISM While HPVMISM generated an alarm in PM I/O, it is a simple
Boolean flag Series C I/O.
FAILOPT FAULTOPT
FAULTVALUE
FAULTST
In PM I/O, FAILOPT is a read/write parameter for IOP blocks. In
addition, the FAILOPT value applies to all channels on that IOP
and FAILOPT is a read only parameter for channel blocks. In
Series C I/O, each channel has its own fault option and a set of
'fault' related parameters.
Additionally, there are a significant number of enhancements
related to handling AO and DO channel faults. When migrating
from PMIO you are encouraged to obtain a thorough
understanding of the AO and DO channels before migrating to
Series C I/O.
(not
implemented)
HDYNCC
HDYNST
HMAXDEVVARS
PM I/O does not support HART version 6.0. Series C I/O supports
these parameters for HART version 6.0.
