51304362-100 Honeywell central processing unit

INQUIRE NOW

Products Name: 51304362-100 Honeywell central processing unit

PRODUCT DESCRIPTION

Brand:   Honeywell

Model number: 51304362-100

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.17kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

Support for DO channel ganging

The UIO-DO channel is now enhanced to support ganging for enabling the delivery of more

current output to the field (maximum current output of up to 2.0 Amperes). This is accomplished

using the existing UIO hardware. DO channel ganging simply requires software configuration of

up to four adjacent DO channels of the UIO module and appropriate channel wiring accordingly.

ATTENTION

l Up to four DO channels can be ganged at a time.

l UIO-channel 32 cannot be ganged with channel 1.

Support for pulse counting functionality

The UIO module DI channel is capable of providing pulse counting functionality. However, only

four DI channels (channels 15, 16, 17 and 18) support pulse counting functionality.

The UIO-DI channel pulse counting supports counting up to 10 KHz of input pulse frequency.

The UIO DI channel configuration consists of simply setting the Digital Input Type parameter to

“Accum” from the Configuration tab of the DI channel.

- 33 -

ATTENTION

Though UIO supports redundancy, it does not support pulse count synchronization.

Therefore, after a switchover the counters are reset and restart at 0. If pulse count

synchronization is required, you must use the Series C Pulse Input Module.

Features of UHIO

The key features of the UHIO are:

l Supports both redundant and non-redundant configuration for C300 Controller, UIO module,

and CF9.

l Supports interchangeability of Series C components.

l Minimizes the effort for rewiring.

The UHIO also supports the following features.

l Provides mechanical connection to the TDC 2000 cabinet Backplane.

l Supports cabinet ground connections through the IOTA mounting screws.

l Provides electrical-mechanical connection to the IOM.

l Provides electrical-mechanical connection to the redundant IOL cable pair.

l Supports 24V fused electrical connections to the IOM(s) - Series C 24V and COM power supply.

l Supports a signal common ground.

l Supports precision resistors for measuring analog inputs.

The UHIO’s CSA General Purpose certification is applicable within Data Hiway (TDC 2000) cabinets

with the Series C Power supply SPS5792-142935 (HPN 51454517-100). If any modifications have

occurred since first installation, the UHIO’s CSA General Purpose certification is voided and it is

the responsibility of the end user to ensure they are still conforming to all applicable agency rules

and regulations. The original TDC Basic Power Supplies do not support the UHIO CSA General

Purpose Certification.

CE Mark certification

The UHIO's CE Mark is only applicable for installations within Data Hiway (TDC 2000) cabinets with

the Series C Power supply SPS5792-142935 (HPN 51454517-100). It is assumed that the state of

as shipped and as first installed has been maintained for all applicable installations. For

installations that do not satisfy the previously mentioned conditions, the end user is responsible to

ensure that they conform to all applicable agency rules and regulations.

CC-HUIO12

The above constraints also apply to the CC-HUIO12 IOTA. Note that the CC-HUIO12 was tested

with TCB cable 51192054 only. Using the original TCB cable 30731611 with adaptor cable 51202979

may not pass CE Mark tests. For the conducted immunity test between 150kHZ and 250kHz, the AI

accuracy was 4.3% instead of its normal 0.1% at room temperature.
