Brand： Honeywell
Model number：51309204-175
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.27kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Description:
All Series C components feature an innovative design that supports enhanced heat management. This unique look
provides a significant reduction in overall size for the equivalent function.
The unique features of Series C I/O include:
• I/O Module and field terminations are combined in the same area. The I/O Module is plugged
into the IOTA to eliminate the need for a separate chassis to hold the electronics assemblies.
• Two level “detachable” terminals for landing the field wiring in the enclosure, providing easier
plant installation and maintenance.
• Field power is supplied through the IOTA, with no need for extra power supplies and the
associated craft wired marshalling.
• Redundancy is available directly on the IOTA without any external cabling or redundancy control
devices, by simply adding a second IOM to an IOTA.
• The Series C innovative styling is one of its unique features. This styling includes features to
facilitate the effective use of control hardware in a systems environment. These features include:
• Vertical mounting for more effective wiring since most field wiring applications require entry from the top or bottom of
the systems cabinet.
• An “information circle” for a quick visual cue to draw the Maintenance Technician’s eye to important status
information.
• “Tilted” design for effective heat management within the cabinet enclosure. Since Series C allows for a significant
increase in cabinet density, an effective heat management system is critical for high systems availability.
• Input and output circuits are protected from shorts to alleviate the need for in-line fusing, reducing installation and
maintenance costs.
Function
The Analog Output (AO) Module delivers high-level constant current to actuators and recording/indicating devices.
Notable Features
• Extensive self-diagnostics
• Optional redundancy
• Safe-state (FAILOPT) behaviors configurable on a
per channel basis
• Output read-back and alarm on discrepancy
• Non-incendive output
FAILOPT
Series C AO module supports the FAILOPT parameter on a per channel basis. The user can configure each channel to
either HOLD LAST VALUE, or SHED to a SAFE VALUE. The Output will always go to zero, the safe state, if the IOM
device electronics fails.
Open-wire Detection
This Series C IO function will be able to detect and annunciate open field wire with a Channel Soft Failure indication
