Configuring the setpoint ramp
You can configure a single setpoint ramp to occur between the current local setpoint and a final local
setpoint over a time interval of from 1 to 255 minutes. You can RUN or HOLD the ramp at any time.
Procedure
75HTable 5-17 lists the procedure for configuring the Setpoint Ramp 1 or 2 parameters. The procedure for
Setpoint Program is in Section 6 – Setpoint Ramp/Soak Programming Option.
Table 5-17 Procedure for configuring a single setpoint ramp
Step Operation Press Action/Result
1 Select SP RAMP 1 or
SP RAMP 2 Set Up
group
SET
UP
Until you see:
Upper Display: SET UP
Lower Display: SP RAMP X
X = 1 or 2
2 Select the Setpoint Ramp
function
FUNC Until you see:
Upper Display: DISABL
Lower Display: SP RAMP X
3 Enable Setpoint Ramp ▲ Until you see:
Upper Display: ENABLE
Lower Display: SP RAMP X
NOTE: You cannot change the current local setpoint if
the setpoint ramp function is enabled. Make sure SP
PROG is disabled.
4 Set the Ramp Time FUNC Until you see:
Upper Display: The ramp time in minutes
Lower Display: TIME MIN
▲ or ▼ Change the upper display value to the number of
minutes in which you want the final setpoint to be
reached.
Setting Range = 1 to 255 minutes
NOTE: Entering “0” implies an immediate step change
to the final SP.
5 Set the Final Setpoint
value
FUNC Upper Display: The final setpoint value
Lower Display: FINAL SP
6 ▲ or ▼ Change the upper display value to the desired final
setpoint value.
Setting Range = within the setpoint limits
