e
Notes
trace assigned parameter on Station Trend
display.
Trend
Parameter
- Yes Valid parameter name for a parameter associated
with given point that is configured for history
collection.
Description - No Provides a brief description of the entered
parameter.
Number of
Groups
GROUP.NUMPARAMS Yes Defines the number of group parameters to be
included in Groups Configuration table.
Group # - Yes Defines Group number to be associated with this
group parameter.
Pos # - Yes Defines number of position configured
parameter will occupy in the Station Group
display.
Group
Parameter
- Yes Valid parameter name for a parameter associated
with the given point that is configured in the
system.
Description - No Provides a brief description of the entered
parameter.
9.7.1 Prerequisites
l Control Builder is running
l A Series C I/O control module was created
9.7.2 To configure the Server Displays tab.
1. Under the Server Displays tab, enter the appropriate information to specify related Point Detail
Display, Group Detail Display, and Associated Display along with values for appropriate
parameters to define Trends and Groups for display. If necessary, press F1 to access on-line
help for assistance during this step
2. Click OK on the configuration form to accept all configuration selections made on each
configuration tab and to return to the Project tree.
9.8 Configuring Control Confirmation tab - IOM block
The Control Confirmation tab is common to all configuration forms for tagged blocks in Control
Builder. If you have an optional Electronic Signature license, you can configure electronic
signature information for the tagged block through this tab on the block's configuration form in
Control Builder.
The Electronic Signature function aligns with the identical Electronic Signatures function that is
initiated through Quick Builder and Station for Server points.
When this block is loaded to a controller,
