The Experion® Process Knowledge System (PKS) is Honeywell’s unified control system for process, business, and asset
management that helps industrial manufacturers increase their profitability and productivity. Experion takes customers well
beyond distributed control system (DCS) functionality with an advanced automation platform solution and innovative
application integration to improve business performance and peace of mind.
Refer to the “Experion CEE-based Controllers and I/O Overview” (document number EP03-290-xxx) for prerequisite
information. This document is written with the expectation that the reader understands the information and concepts covered
in the overview document.
Description:
The ExperionPKS platform comprises many different integrated hardware and software solutions depending upon the needs
of the application. This pictured architecture is a representation of many of the possible nodes that can be utilized in the
ExperionPKS architecture. Note that the architecture is highly scalable and not all nodes are necessary or required.
Notes [1] for FTE Ethernet:
1. When any FTEB or C300-20ms is present in the FTE Community, or if EtherNet/IP™ (EIP) is being deployed by
one or more C300s in the FTE Community, the limit is 200 FTE Nodes.
2. SCADA connected PLCs can still be connected via ControlNet/PCIC when C200s, C200Es, or C300s reside on
the FTE Supervisory Control Network.
3. SCADA PLCs do not count as “Controllers” against this limit on FTE
4. 60 controllers in any combination of CEE based Controllers (C200, C200E, C300, UOC, vUOC) and/or CDAcapable controllers (Safety Managers (Max 20), and/or PMD Field Controllers (Max 25), and/or EHPMs (defined
in Section 16.3 EHPM Capacities)
