CC-TAIX01 Honeywell Power Supply Modules

INQUIRE NOW

Products Name: CC-TAIX01 Honeywell Power Supply Modules

PRODUCT DESCRIPTION

Brand:   Honeywell

Model number:CC-TAIX01

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.26kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

Two-wire transmitter wiring - Analog Input module

The AI IOM/IOTA is optimized for use with classic two-wire transmitters. All 16 channels can accept

inputs from two-wire transmitters without any special wiring or jumper options.

The standard usage is to:

l reserve the first 12 channels of the AI IOM/IOTA for classic two-wire transmitters, and

l use the last 4 channels of the IOM/IOTA to interface any of the supported input styles

(including two-wire transmitters).

Depending on the input style applied to channels 13 through 16, you may need to cut jumpers on

the IOTA and apply wiring to the TB2 terminal block on the IOTA. This is discussed in detail in the

following sections.

 Non two-wire transmitter wiring - Analog Input module

The IOTA is pre-engineered (without custom wiring) to accept sources that are not two-wire

transmitters, but you must use channels 13 through 16.

When sources other than two-wire transmitters are to be interfaced and you have more than 4 per

IOTAs, then:

l the first four must be interfaced to channels 13 through 16, and

l the remainder may be able to interface to channels 1 through 12 (depending on input style)

but you must perform some degree of custom wiring.

NOTE

There are some input styles that simply cannot be applied to channels 1 through 12 - if that

applies to you then you will likely need to purchase an additional IOM/IOTA.

CAUTION

The jumpers on the IOTA are non-repairable; once cut, they stay cut. Careful planning is a

must.

 Custom wiring - Analog Input module

Custom wiring means:

l using additional wires to TB2 (beyond their intended purpose for channels 13 through 16)

l and/or using wires to another termination area in the cabinet engineered on a project-basis.

• Wall or turnstile mounting with enhanced ergonomic vision.

• Stylish and robust design that blends in with elegant premises, as well as manufacturing

environments.

• Access Control and Time and Attendance transits support that allows advanced transits for

both configurations.

• Flexible support of a variety of reading technologies, from proxy to smartcard.

• Innovative system with Honeywell Forge Occupant Experience Mobile Access.

• Embedded I/O removes the need to invest in additional, costly devices.

SPECIFICATIONS

• Modern Design LonWorks Compact reading unit for for multi-reading technology.

• Includes reader (prox, smartcard, BLE) with an 16x2 LCD, a numeric keypad with 16 keys, two

supervised or digital inputs, two powered open collector drain outputs for gate management.

- To be connected to Temaline TS2 controller.

- Refer to compatibility matrix for EBI-Temaline versions that connect to this device.

FC-QPP-0002   Honeywell  Power Supply Modules

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
