The Field Interface/Relay Cards provide the interface connections
between the Control Cards and their respective field connected
gas sensor. In addition, Relay Cards provide alarm outputs to the
field connections.
Description:
The 5701 Series Control System is part of the System 57 family and is
designed to monitor field mounted industrial gas detectors. The principal
features of the system are:
* Provides up to 16 channels of gas detection in a standard 19'' subrack using a 3U card format.
* Provides up to eight channels of gas detection in a half 19'' subrack using a 3U card format.
* Racking available for both front and rear access field wiring.
* Simple field connections for wire up to 2.5mm2.
* Single channel mode of operation for high integrity systems.
* Channel Control Cards removable without disturbing other wiring.
* Catalytic bridge or 4 - 20mA input.
* Optional alarm change-over relay outputs.
* Multi-alarm mode for master, zoned and voted alarms.
* Rising, falling, STEL and LTEL / RATE alarm outputs.
* Update alarm on individual or multi channel alarms.
* Remote inhibit and reset inputs.
* Time delay on switch on and/or switch off of relay outputs.
* Optional 0 - 20mA or 4 - 20mA isolated monitor output.
* Easy to calibrate and operate using a dedicated Engineering card.
* EMC compliant.
* Options provided via Engineering Card:
* Master Alarm Update.
* Event Printers.
* Serial communication using Modbus protocol.
