Input CC-PAIH51 and Cx-PAIH01 use the same IOM block, that is, AI-HART. The configuration
and implementation mentioned in note 1 applies to the HART Analog Input module.
4. With R410, a new model of HART Analog Output CC-PAOH51 is introduced. The HART Analog
Output CC-PAOH51 and Cx-PAOH01 use the same IOM block, that is., AO-HART. The
configuration and implementation mentioned in note 1 applies to the HART Analog Output
module.
5. With R410, a new model of Digital Input 24V DC CC-PDIL51 is introduced. The Digital Input
24V DC CC-PDIL51 and Cx-PDIL01 use the same IOM block, that is, DI-24. The configuration
and implementation mentioned in note 1 applies to the Digital Input 24V module.
6. With R410, a new model of Digital Output 24V DC CC-PDOD51 is introduced. The Digital
Output 24V DC CC-PDOD51 and Cx-PDOB01 use the same IOM block, that is, DO-24B. . The
configuration and implementation mentioned in note 1 applies to the Digital Output 24V
module.
7. Starting with R430, a new model of Low Level Analog Input Mux CC-PAIM51 is introduced.
8. The UIO (CC-PUIO01) has 32 configurable input or output channels. Each channel can be
configured as one of the following:
l Analog Input (0-20mA or 4-20mA active)
l Analog Output (4-20mA active)
l Digital Input (with or without line monitoring)
l Digital Output (with or without line monitoring)
9. The UIO (CC-PUIO31) module is introduced with R432 and has 32 configurable input or output
channels that are identical to the UIO (CC-PUIO01) module.
ATTENTION
Series C IO modules introduced in ExperionPKS R410.x release should not be used
with its prior ExperionPKS releases R400.x. Do not try to downgrade the firmware of
Series C IO Modules introduced in ExperionPKS R410.x release, as IOM will not
work and it is difficult to recover as well.
