FF-SEDGE6G2-1M-C Honeywell Power module Brand new

You can wire control output 1 or 2 for 4-20 mA output.

The prerequisites are:

· Model Number - Table 2 = 1X, 6X, X1, X6

Refer to Figure 2-16 and follow the procedure in Table 2-15 to wire 4-20 mA control outputs.

Table 2-15 4-20 mA control output wiring

Step Action

1 Open the recorder door. Loosen the captive screw in the chart plate and swing the plate out.

2 Locate connector J1 near the top of the control output #1 printed circuit board (refer to Figure

2-16 for location).

3 Remove the unwired plug from J1.

4 Run the output wires through the desired knockout.

5 For CE Mark conformity:

· Install the ferrite filter as shown in Figure 2-11.

· Install the .0047µF capacitor as shown in Figure 2-16.

6 Strip insulation from the end of each wire.

7 Loosen the screws in plug J1 terminals and position the plug as you would to plug it into J1.

8 Observing the polarity, insert the wires into the appropriate screw clamps as shown (refer to

Figure 2-16). Tighten the screws to secure the wires.

9 Install the wired plug into J1.

10 Locate jumper position W6/W7 on the bottom left portion of the board. Make sure W7 position

is selected for 4-20 mA output.

11 Repeat steps 2 through 10 for control output #2 printed circuit board as applicable.

ATTENTION

Be sure that the 4-20 mA current output is aligned. Refer to subsection 8.2 Current

Proportional Output Calibration.

TIP

The 4-20 mA output can be used as a retransmission output if it is not used as a control

output.
