Introduction

There is a SP RAMP set up group for each control loop. Use the prompts to select the settings for each

loop’s program.

SP RAMP Prompts

Table 6-3 lists all the function prompts for SP RAMP configuration in the order of their appearance. These

prompts are available when SP PROG is enabled in the S PRAMP set up group described in Section 4.

All parameters may be changed while the program is disabled or in HOLD.

Table 6-3 SP RAMP prompts and available selections

Lower Display

Prompt

Upper Display

Range of Setting or Selection

Parameter Definition

SPPROG

DISABL

ENABLE

SETPOINT PROGRAMMING—This must be set to

ENABLE for the setpoint program feature to work, and

for the associated operating parameters to be displayed.

SP RAMP and SP RATE must be disabled. (See

Section 4.)

DISABL—Disables Setpoint Programming

ENABLE—Enables Setpoint Programming

RECYCLES 0 to 99 RECYCLES—Enter the number of times the program

selected for execution will be repeated.

SOAKDEV –99.9 to 99.9 engineering units SOAK DEVIATION—Enter the acceptable deviation

from setpoint during a soak cycle. If the PV differs from

the setpoint by more than the value of SOAKDEV, soak

time is frozen.

There are no guaranteed soaks if SOAKDEV = 0.

PROFILE 1 to 6 PROFILE used by Setpoint Program. This can also be

set or changed when viewed in the lower display and the

current profile is in the HOLD state.

STATE DISABLE

HOLD

Determines the state of the program after it completes

the final program segment cycles. If you select DISABL,

you must enable the program through the function

prompt before you can run the program again. If you

select HOLD, you can run the program again by

pressing the RUN/HOLD key.

RECOVERY ENABLE

DISABL

This mode, when enabled, will allow the SP Program to

continue from the point at which the power was removed

when there is a power interruption.

PROG END ENABLE

DISABL

Determines the status of the control output after the

program is run. If you select LASTSP, the recorder

controls to the last setpoint value which becomes the

LSP. For FSAFE selection, the recorder is switched to

manual mode and to the selected failsafe output value.
