FS-TSDI-16UNI Honeywell

FS-type modules are non conformal coated modules.FC-type modules are conformal coated modules. Conformal coated modules have the letters"cc" preceding the version number.

Modules with suffx code V 1.1 or CCV1 .1 and higher have an improved design. There are nofunctional changes.

The output current is limited to 35 0mA at 70C, far details see "Maximum output load" onpage 354. For general information about the maximum curren t see secfon "G eneral informationabout output modules on page 344.

Description:

The SDO-0824 module has the following specifications:

Genera

Type numbers1 2.

FS-SDO-0824 V1.2

FC-SDO-0824 CCV1.2

Power

Approvals.

S pace requirements:

Power requirements:

CE, TUV UL,CSA FM

4 TE, 3 HE (= 4 HP, 3U)

5 Vdc, 25 mA

24 Vdc internal, 25 mA

24 Vdc external, 70 mA (without output load)

Output

Number of output channels:

Output specification:

Maximum current:

Maximum lamp load:

Maxim um load capac itance.

Voltage drop:

Off current:

WDG input current:

8

24 Vdc solid-state source, short-c ircuit proof

550 mA3

120 mA (2.9 W)

1 F

<2.0 Vde at 500 mA

<01mA

8 mA

Key coding

See section "Key coding" on page 17)

Module code:

holes

A9,C9

Chassis code:

large pins

A9,C9

FS-type modules are non conformal coated modules.FC-type modules are conformal coated modules. Conformal coated modules have the letters"cc" preceding the version number.

Modules with suffx code V 1.1 or CCV1 .1 and higher have an improved design. There are nofunctional changes.

The output current is limited to 35 0mA at 70C, far details see "Maximum output load" onpage 354. For general information about the maximum curren t see secfon "G eneral informationabout output modules on page 344.
