Honeywell CC-PDIL01

Honeywell CC-PDIL01 Control Firewall Module

Brand:   Honeywell

Model number:CC-PDIL01

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.5kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Honeywell CC-PDIL01 Control Firewall Module


INQUIRE NOW

Products Name: Honeywell CC-PDIL01

PRODUCT DESCRIPTION

IOTA Sizing is nominal (6in = 152mm, 9in =228mm, 12in =304mm, 18in = 457mm)I/O modules are associated with their

respective IOTAs in the table below. An I/O Module is supported by one or more IOTAs

Description:

• High Level Analog Input /HART Input Module (16pt) – The High Level Analog Input Module supports both high

level analog and HART inputs. Analog inputs are typically 4-20mA DC for both traditional and HART devices. HART

data can be used for status and configuration. HART data, such as the secondary and tertiary variables, can also be

used as process control variables. Two versions are available.

• High Level Analog Input w/o HART (16pt) - The High Level Analog Input Module supports high level analog inputs

Analog inputs are typically 4-20mA DC for traditional devices.

• Analog Output/HART Output Module (16pt) – The Analog Output Module supports both standard 4-20mA DC

outputs and HART transmitter outputs. Two versions are available.

• Analog Output w/o HART (16pt) – The Analog Output Module supports standard 4-20mA DC outputs.

• Digital Input 24 VDC (32pt) – Digital input sensing for 24V signals. Two versions are available.

• Digital Input High Voltage (32pt) – Digital input sensing for 110 VAC, 220 VAC, 125VDC.

• Digital Output 24 VDC (32 pt) – Current sourcing digital outputs. Outputs are electronically short-circuit protected.

Two versions are available.

• Relay Digital Output (32 pt) – Digital output with NO or NC dry contacts. Can be used for low power or high power

applications.

• Temperature Multiplexer (64 pt) – Provides thermocouple (TC) and resistance temperature device (RTD) inputs.

The Multiplexer supports up to four, field proven PMIO FTAs.

• Temperature Multiplexer (64 pt) – Provides thermocouple (TC) and resistance temperature device (RTD) inputs.

The Multiplexer supports up to four, field proven PMIO FTAs

• Pulse Input (8pt) – Provide linear counting, PV generation, and Quaduature Input for Custody Transfer

• Universal Input Output (32 pt) - Supports 32 channels of user configurable IO. Choices available – analog input,

analog output, digital input, and digital output.

Series C field connectors accept up to 12ga AWG / 2.5mm stranded wire.
