Honeywell EDA70
Brand： Honeywell
Model number：EDA70
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.5kg
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Honeywell EDA70 Output Point I/O Module
The Experion LX platform comprises many different integrated hardware and software solutions depending upon the
needs of the application. This pictured architecture is a representation of many of the possible nodes that can be used
in the Experion LX architecture. Note that the architecture is highly scalable and not all nodes are necessary or
required.
This document provides technical information for the Series 8 Profibus Gateway Module, released with Experion LX.
The PROFIBUS Gateway Module provides a common module platform to support the interface to the PROFIBUS DP
and the C300 Controller. The PGM is developed in the Series 8 form factor for use with the C300 Controller. The Series
8 form factor employs an Input Output Termination Assembly (IOTA) and an electronics module which mounts and
connects to the IOTA.
As a PROFIBUS gateway, PGM is always a master and communicates with the PROFIBUS compatible slave devices.
The PGM mounts in the same fashion and shares all characteristics, power and grounding, certifications, and meets all
environmental rating as all other Series 8 components.
The PGM is optionally redundant and supports two DP networks per module.
The PGM supports the following functions.
• Redundancy
• Cold start command
• Experion LX by Experion events and alarms
• Experion LX by Experion Bulk Build utility
• Experion LX by Experion import/export functionality
• Qualification and Version Control
• Peer-to-peer communications
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
