Honeywell FC-GMLA16

The Honeywell IPC-620 adapter chassis is provided with the

front cover. The cover is hinged so it opens easily to allow

access to the adapter cards and field wiring connectors.

The cover can also be easily removed. Angle brackets for

mounting the chassis in the control cabinet are also provided.

Description:

Emphatec’s MIBRIDGE® offering

includes an interface system to replace

Honeywell’s IPC-620 I/O racks. The

MIBRIDGE® solution includes a chassis

that replaces the IPC-620 chassis

(same footprint in the control cabinet),

adapter cards for 6/8, 16 and 32

channel I/O cards, and cables.

Field wiring connectors are removed

from the existing IPC-620 I/O cards and

re-installed on the MIBRIDGE® adapter

cards. The adapter card accepts the

field wiring connectors directly meaning

there is no need to modify the field

wiring. This saves time and more

importantly eliminates the chance of

wiring errors. A cable interfaces each

adapter card to the new control system.

Adapter cards are specific to the

number of I/O channels on the original

IPC-620 I/O card, not the type of I/O.

For example, all 16 channel IPC-620

I/O cards, regardless of whether they

are input or output cards, are replaced

by a common 16 channel adapter card.

The cable to the new control system

can be generic (provided with flying

leads for connection to the new I/O

card) or specific to the new I/O card

(provided with a connector specific to

that I/O card).

The MIBRIDGE® Honeywell IPC-620

solution was designed to allow control

to migrate to Rockwell’s Controllogix

system although it can be used

with other platforms as well. The

Controllogix chassis can be mounted

directly on the front of the MIBRIDGE®

chassis (see photo).
