Click OK.
The IOM block load starts. The Load dialog box displays the progress and the respective
information.
TIP
You can also check load progress through the four-LED display on the front panel
of the IOM. The display changes from NODB to NOEE to OK upon a successful
Load.
If errors are detected, then the errors are displayed in the Load progress dialog box
and you can continue the load or cancel, depending on the nature of the error. It is
recommended that you cancel the load and identify and fix the errors. Each
message includes an error code in parentheses. Note the last number in the string.
For more information about the error code, see Control Builder Error Code Reference.
4. Once the load completes and the dialog box closes, click the Monitoring view.
IOP/IOM icons now appear in Monitoring view. The default state for a loaded IOP/IOM is active
or color code green.
ATTENTION
When you load the imported IOMs, ensure that all the channel type (PNTTYPE) is
identical with the loaded channels. If the channel type is not identical, then the
corresponding channels must be deleted from the Monitoring view before loading
the imported IOM.
l Loading with the IOM block missing on the IOLINK
l Reloading the IOM block from Project or Monitoring
l Reviewing IOM re-configuration rules
11.2.3 Loading with the IOM block missing on the IOLINK
IOM blocks can be loaded without the IOM present on the link, but the following occurs:
l Errors are returned on load and the IOM icon appears red in the Monitoring Tab.
Refer to Reviewing the Series C I/O block icons in Control Builder to view icon appearance
based on current status.
l Since the IOM is responsible for error checking the loaded data, you must either reload the
IOM or perform a checkpoint restore when the IOM later appears on the I/O Link.
11.2.4 Reloading the IOM block from Project or Monitoring
The behavior of the IOM when the IOM is reloaded from the Project view or the Monitoring view is
explained as follows:
.
