TIP
l You can also check the load progress through the four-LED display on the
front panel of the I/O Link Interface Module. The display changes from NODB
to NOEE to OK upon a successful load.
l If errors are detected, then they are displayed in the Load progress dialog box
and you can continue the load or cancel, depending on the nature of the error.
It is recommended that you cancel the load and identify and fix the errors.
Each message includes an error code in parentheses. For more information
about the error code, see Control Builder Error Code Reference.
3. Click the Monitoring view after the load is complete and the dialog box is closed.
I/O channel block icons now appear in Monitoring view. The default state for a loaded I/O
channel is active or color code green.
11.4 Behavior of IOMs and CMs under version control
11.4.1 IOM version mismatch between the Project view and
Monitoring view
When you load the channel, the IOM is also loaded along with the channel. The IOM is loaded as
LWA if the IOM does not have the delta flag. The LWA icon is displayed for the IOM in the Load
Operation dialog.
From the Project view, if you load or reload a channel assigned to an IOM that is under version
control, then the following channels belonging to the same IOM are also loaded as dependents:
l Unloaded channels are loaded.
l Channels having delta flag are inactivated and loaded.
l Channels with "Load While Active" changes are "Loaded While Active".
In addition, the IOM to which the channels are assigned is also selected as dependent for load.
However, the LWA icon is displayed in the Load Operation dialog box for the IOM and for the
channel which has LWA changes.
.
