Configuration Tools
External Three Button Configuration Option
Suitable for all electrical and environmental requirements,
SmartLine offers the ability to configure the transmitter and
display via three externally accessible buttons when a
display option is selected. Zero/span capabilities are also
optionally available via these buttons with or without
selection of the display option.
Internal Two Button Configuration Option
The Simple display has two buttons that can be used for
Basic configuration such as re ranging, PV Engineering unit
setting, Zero/Span settings and Loop testing and calibration
functions.
Handheld Configuration
SmartLine transmitters feature two-way communication and
configuration capability between the operator and the
transmitter. All Honeywell transmitters are designed and
tested for compliance with the offered communication
protocols and are designed to operate with any Standards
compliant handheld configuration device.
Personal Computer Configuration
Honeywell’s SCT 3000 Configuration Toolkit provides an easy
way to configure Digitally Enhanced (DE) instruments using a
personal computer as the configuration interface. Field Device
Manager (FDM) Software and FDM Express are also
available for managing HART & Fieldbus device
configurations.
Modular Design
To help contain maintenance & inventory costs, all ST 700
transmitters are modular in design supporting the user’s
ability to replace meter bodies, add indicators or change
electronic modules without affecting overall performance or
approval body certifications. Each meter body is uniquely
characterized to provide in-tolerance performance over a wide
range of application variations in temperature and pressure
and due to the Honeywell advanced interface, electronic
modules may be swapped with any electronics module
without losing in-tolerance performance characteristics.
Modular Features
• Meter body replacement
• Exchange/replace electronics/comms modules*
• Add or remove integral indicator*
• Add or remove lightning protection (terminal connection)*
* Field replaceable in all electrical environments (including IS)
except flameproof without violating agency approvals.
With no performance effects, Honeywell’s unique modularity
results in lower inventory needs and lower overall
operating costs.
