Introduction
Part of the SmartLine
family of products, the STD700 is
suitable for monitoring, control and data acquisition featuring
piezoresistive sensor technology. By combining pressure
sensing with on chip temperature compensation capabilities
STD700 offers high accuracy, stability and performance over a
wide range of application pressures and temperatures. The
SmartLine family is also fully tested and compliant with
Experion
PKS providing the highest level of compatibility
assurance and integration capabilities. SmartLine easily meets
the most demanding application needs for pressure
measurement applications.
Best in Class Features:
• Accuracies up to 0.05% of span standard & 0.04% of span
optional
• Stability up to 0.02% of URL per year for 10 years
• Automatic static pressure & temperature compensation
• Rangeability up to 100:1
• Response times as fast as 100ms
• Alphanumeric display capabilities
• External zero, span, & configuration capability
• Polarity insensitive electrical connections
• Comprehensive on-board diagnostic capabilities
• Integral Dual Seal design for highest safety based on
ANSI/NFPA 70-202 and ANSI/ISA 12.27.0
• World class overpressure protection
• Full compliance to SIL 2/3 requirements.
• Modular design characteristics
• Available with additional 4-year warranty
