Brand：siemens
Model number：16256-91/6
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.35kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Description:
Phase position signal A to B 90 °
Edge spacing at
• 300 kHz / min. 0.45 µs
Length of cable to subsequent electronics
• max. 100 m
LED failure monitoring High impedance driver
Resolution
• max. 1024
Precision 63 "
Speed / electric
• max. 17600 1/min
Speed / mechanical / max. 12000 1/min
Friction torque at 20°C / max. 0.01 N·m
Starting torque at 20 °C / max. 0.01 N·m
Shaft load capacity
• at n > 6000 rpms
• axially, max. 10 N
• radially on shaft end, max. 20 N
• at n ≤ 6000 rpms
• axially, max. 40 N
• radially on shaft end, max. 60 N
External diameter / of rotary encoder shaft 6 mm
Length of encoder shaft 10 mm
Angular acceleration / maximum 100000 rad/s²
Moment of inertia of the rotor 0.00000145 kg·m²
Vibration 55 to 2000 Hz according to DIN IEC 60068-2-
6 / max.
300 m/s²
Shock according to EN 60068-2-27
• 2ms, max. 2000 m/s²
• 6ms, max. 1000 m/s²
IP degree of protection
• without shaft input IP67
• with shaft input IP64
Ambient temperature / during operation
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Relevant details：
1FT5066-0AK71-1-Z
3TK2827-1AJ20
3TY7561-1A
6ED7193-4CF50-0AA0
6EP1332-1SH12
6ES7132-4BD32-0AA0
6ES7193-4CD30-0AA0
6ES7214-1AC01-0XB0
6ES7810-5CC10-0YR5
6DR2800-8J
6ES7214-1BD23-0XB8
