6ES7134-4GB10-0AB0 SIEMENS

Load voltage L+

● Rated value (DC) 24 V; From power module

● Reverse polarity protection Yes

Input current

from load voltage L+ (without load), max. 30 mA

from backplane bus 3.3 V DC, max. 10 mA

Output voltage

Power supply to the transmitters

● present Yes

● short-circuit proof Yes; 60 mA (for both channels)

Power loss

Power loss, typ. 0.6 W

Address area

Address space per module

● Address space per module, max. 4 byte

Analog inputs

Number of analog inputs 2

permissible input current for current input (destruction

limit), max.

40 mA

Cycle time (all channels) max. Number of active channels per module x basic conversion time

Input ranges

● Current Yes

Input ranges (rated values), currents

● -20 mA to +20 mA Yes; 50 Ohm

● 4 mA to 20 mA Yes; 50 Ohm

Cable length

● shielded, max. 200 m

Analog value generation for the inputs

Measurement principle integrating
