6GK7443-5FX01-0XE0 Siemens

SIMATIC NET, CP 443-5 BASIC COMMUNICATIONS PROCESSOR

FOR CONNECTING SIMATIC S7-400 TO PROFIBUS, FMS, S5-

COMPATIBLE PG/OP AND S7 COMMUNICATION

Transmission rate

Transfer rate

● at the 1st interface / acc. to PROFIBUS 9.6 kbit/s ... 12 Mbit/s

Interfaces

Number of interfaces / acc. to Industrial Ethernet 0

Number of electrical connections

● at the 1st interface / acc. to PROFIBUS 1

Type of electrical connection

● at the 1st interface / acc. to PROFIBUS 9-pin Sub-D socket (RS485)

Supply voltage, current consumption, power loss

Type of voltage / of the supply voltage DC

Supply voltage / 1 / from backplane bus 5 V

Supply voltage 5 V

Relative symmetrical tolerance / at DC

● at 5 V 5 %

Power loss [W] 6.5 W

Ambient conditions

Ambient temperature

● during operation 0 ... 60 °C

● during storage -40 ... +70 °C

● during transport -40 ... +70 °C

Relative humidity

● at 25 °C / without condensation / during

operation / maximum

95 %

Protection class IP IP20

Design, dimensions and weight

Module format Compact module S7-400 single width

Width 25 mm

Height 290 mm

Depth 210 mm

Net weight 0.7 kg

Number of units

● per CPU / maximum 14

● Note depending on CPU type

Performance data / open communication

Number of possible connections / for open

communication / by means of SEND/RECEIVE

blocks / maximum

32

Amount of data

● as user data per connection / for open

communication / by means of SEND/RECEIVE

blocks / maximum

240 byte
