The dimensional drawing of the module on the mounting rail, as well as a dimensional
drawing with open front cover, are provided in this appendix. Always observe the specified
dimensions for installation in cabinets, control rooms, etc.
Address space for configuration as 2 x 8-channel DI 16x24VDC BA S
For the configuration as a 2 x 8-channel module, the channels of the module are divided into
multiple submodules. The submodules can be assigned to different IO controllers when the
module is used in a shared device.
The number of usable IO controllers depends on the interface module used. Please observe
the information in the manual for the particular interface module.
Contrary to the 1 x 16-channel module configuration, each of the two submodules has a
freely assignable start address.
Address space for configuration as 1 x 16-channel DI 16x24VDC BA MSI
The channels 0 to 15 of the module are copied in up to four submodules with configuration 1
x 16-channel module (Module-internal shared input, MSI). Channels 0 to 15 are then
available with identical input values in different submodules. These submodules can be
assigned to up to four IO controllers when the module is used in a shared device. Each IO
controller has read access to the same channels.
The number of usable IO controllers depends on the interface module used. Please observe
the information in the manual for the particular interface module.
Value status (Quality Information, QI)
The meaning of the value status depends on the submodule involved.
For the 1st submodule (=basic submodule), the value status is not relevant.
For the 2nd to 4th submodule (=MSI submodule), the value status 0 indicates that the value
is incorrect or the basic submodule has not yet been configured (not ready).
The figure below shows the assignment of the address space with submodules 1 and 2.
