Brand：siemens
Model number：6ES7138-4DA04-0AB0
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.23kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Description:
Modular, freely programmable automation stations for HVAC and building control
systems.
Management functions (alarm management with alarm routing, schedulers,
trend functions, remote management, access protection with individually defined
user profiles and categories).
For stand-alone applications or for use within a device or system network.
BTL-tested BACnet communications on LonTalk, PTP or IP, compliant with
BACnet standard (Rev. 1.12 -for Desigo V6.0 and later) including B-BC profile.
AMEV profiles AS-A and AS-B to recommendation "BACnet 2011 - Version 1.2
(for Desigo V6.0 and later)".
Freely programmable, using the D-MAP programming language (close
resemblance to CEN standard 11312). All function blocks, available in libraries,
can be graphically connected.
Engineering and commissioning using the Desigo Xworks Plus tool.
Connection of field devices to a customized mix of TX-I/O modules.
Connection of installed PTM-I/O modules – the perfect solution to migrate legacy
systems.
Connection of TX Open modules to integrate third-party devices such as
variable speed drives, pumps or energy counters.
Connection of detached I/O islands with integration.
Connection of LonMark® compatible devices
Low voltage protection and start-up management to protect the devices against
fluctuating voltage.
Scalable range of touch panels, Web solutions and operator units.
Overview of automation stations – modular series
Connection of TX-I/O modules, TX Open modules, PTM-I/O modules via PXXPBUS
and LonWorks devices via PXX-L11/12.
Activation of generic Web operation with PXA40-W1
PXX-PBUS : The extension module allows connecting installed PTM-I/O
modules to PXC50/100/200…D automation stations, making them the perfect
solution to migrate legacy systems.
PXX-.. device Type Data sheet
PBUS extension module PXX-PBUS CM1N9283
Note: One supply module TXS1.12F10 is required as bus supply for the P-bus
for each P-bus strand. A TXS1.12F10 can supply max. 64 load units (1 LU =
12.5 mA, DC 24 V)
Limits of the PXX-PBUS extension module:
DB (Function blocks instances): 1500
Trends: 100
Local BACnet references. 100
To prevent high cycle times of the PXX-PBUS extension module:
Only use PXC100-(E).D controllers together with PXX PBUS; do not use
PXC 200 controllers.
Do not connect PXX-L11 or PXX-L12 or PX Web modules (WO-W2) together
with PXX-PBUS on the same controller.
Do not use WebServer functionality on PXC, when using PXX-PBUS.
Do not extend existing applications from PXC128-U or PXC64-U with new
functionality.
