– TXM1.8D: 8 inputs, each with a three-color LED (green, yellow or red)
– TXM1.16D: As TXM1.8X, but 16 inputs, each with a green LED
• 8 or 16 digital inputs; individually configurable for status signals,
status pulses (with a memory function) or counter pulses (up to 10 Hz)
• Compact DIN format, small footprint
• Separate terminal base and plug-in I/O module for convenient handling
– Self-establishing bus connection for maximum ease of installation
– Terminal isolation function for fast commissioning
– I/O module replaceable in seconds, without rewiring and without affecting
the full functioning of the remaining I/O modules
• All terminals are directly on the I/O modules, allowing direct connection of
field devices without additional terminal strips.
• Simple strategy for operation and display
– I/O status LED for each I/O point; mode of operation (N/C or N/O) depends
on I/O function
– LEDs for fast diagnostics
• Double-sided labels for identification of all I/O points
• The I/O status LEDs indicate the status of the inputs and outputs (peripheral
devices)
• The LEDs on the TXM1.16D are green
• In the case of the TXM1.8D the LEDs are three-colored. If the I/O function supports
it, the module can display Alarm = red and Service = yellow, besides Normal = green
• The LEDs are also used for diagnostic purposes
• The module status LED illuminates the transparent address key
• The (green) LED shows the status of the module as a whole (as opposed to the
status of the I/O points)
• It is also used for diagnostics
• The module operates only with the address key inserted
• The module address is mechanically encoded in the address key
• When replacing the plug-in I/O module, the address key must be swiveled outward. It
remains plugged into in the terminal base.
