AAI141-H00/K4A00 Yokogawa Input module

Product Overview

The AAI141-H00/K4A00 is a 16-channel, non-isolated analog input module from Yokogawa Electric Corporation. It is designed for use in Yokogawa's distributed control

system (DCS) applications and can measure a variety of industrial process signals, including voltage, current, and temperature.

Product Specifications

• Number of channels: 16

• Input type: 4 to 20 mA DC or -10 to +10 V DC

• Input impedance: 2 MΩ

• Accuracy: ±0.1% of full scale

• Resolution: 0.01% of full scale

• Conversion time: 10 ms

• Power consumption: 2 W

• Operating temperature: -20 to 70°C (-4 to 158°F)

• Humidity: 10 to 90% RH (non-condensing)

• Dimensions: 107.5 x 94 x 32.8 mm (4.23 x 3.70 x 1.29 in)

• Weight: 1.5 kg (3.3 lb)

Product Advantages

• High accuracy and resolution: The AAI141-H00/K4A00 provides high accuracy and resolution, making it suitable for demanding applications.

• Wide input range: The module can accept a wide range of input signals, including voltage, current, and temperature.

• Fast conversion time: The module has a fast conversion time of 10 ms, which ensures accurate and timely data acquisition.

• Low power consumption: The module consumes only 2 W of power, making it energy efficient.

• Wide operating temperature range: The module can operate in a wide temperature range of -20 to 70°C (-4 to 158°F), making it suitable for use in harsh environments.

Precautions

• Avoid applying excessive voltage or current to the input terminals.

• Do not connect the module to a live circuit.

• Use appropriate grounding and shielding to protect the module from noise and interference.

• Install the module in a location that is free from dust and moisture.

• Regularly inspect the module for any signs of damage.

Product Applications

The AAI141-H00/K4A00 is a versatile analog input module that can be used in a wide variety of applications, including:

• Process control: The module can be used to measure and control a variety of process variables, such as temperature, pressure, flow, and level.

• Machine automation: The module can be used to monitor and control machine parameters, such as speed, position, and torque.

• Test and measurement: The module can be used to measure and record electrical signals for test and measurement applications.
