FLXA21-D-P-D-AB-P1-NN-A-N-LA-N-NN/U/SCT Yokogawa

Models AFV10S,AFV10DField Control UnitDuplexed Field Control Unit(for Vnet/lP and FIO, 19-inch RackMountable Type)

GENERAL

This GS covers the hardware specifications of theField Control Unit (FCU which is the core of thecontrol function of the Field Control Station (FCS)

By installing the control bus interface card into the PCI

Express slot of the PC/AT compatible computer, the

computer is connected to Vnet/IP.

n FUNCTION

Interface between the PCI Express and Vnet/IP

n STANDARD SPECIFICATIONS

Communication Speed

1 Gbps Full Duplex

Connection Specifications

Cable: CAT5e (Enhanced Category 5 cable), UTP

Transmission: 1000BASE-T compliance

Connector: RJ45 connector

Max. distance: 100 m (Distance between VI702 and

Layer 2 switch)

PCI Express Specifications

Applicable revision:

PCI Express CEM Specification 1.0a x1,

2.5 GT/s signaling

This card can be installed in a PCI Express slot (x1

to x16).

This card cannot be installed in a PCI slot.

Voltage

Power supply voltage: 3.3 V ± 9 %

Current Consumption

Max. 2.5 A
