YOKOGAWA ADV161-P00-S2

This GS covers the hardware specifications of the Digital I/O Modules (FIO) that can be installed in the ESB Bus

Node Unit (ANB10S, ANB10D), Optical ESB Bus Node Unit (ANB11S, ANB11D), the ER Bus Node Unit (ANR10S,

ANR10D) and the Field Control Unit (AFV30S, AFV30D, AFV40S, AFV40D, AFF50S, AFF50D, AFV10S, AFV10D).

 Digital Input Modules

The Digital Input Modules receive 32-channel or 64-channel 24 V DC ON/OFF signals.

The ADV151 and ADV161 can be used in dual redundant configuration.

*1: ADV151-E cannot be installed in the ER Bus Node Unit.

*2: ADV151, ADV157 and ADV161 are common every 16-channel. All voltage input signals to be connected (24 V DC) must

be in the same polarity.

*3: The withstanding voltage for using a dedicated cable is 500 V AC (between input signal and system).

 The withstanding voltage for using MIL connector cable depends on the electrical specifications of its cable.

 AC Digital Input Modules

The AC Digital Input Modules receive 16-channel 100 V AC or 220 V AC ON/OFF signals.

They can be used in dual redundant configuration.

Note: AC input signals to the same common should be the same phase.

*1: Input a sine wave, for AC signals.

*1: Connect a spark killer diode when driving DC relay.

*2: The withstanding voltage for using a dedicated cable is 500 V AC (between output signal and system).

 The withstanding voltage for using MIL connector cable depends on the electrical specifications of its cable.
