The following operating instructions are to be observed:
• Never short-circuit or operate battery with the polarities reversed! They are likely to
overheat and explode. Avoid chance short circuiting and therefore do not store batteries in
metal containers and do not place them on metallic surfaces. Escaping lithium is health
hazard.
• Replace battery only with power supply on. Otherwise data may be lost.
A master basic unit can manage up to 31 connection points, such as:
- Series 50 remote units with central extension possibilities: a maximum of 6 extension units
comprising of e. g. a maximum of 8 analog input channels and 8 analog output channels
- Series 30 and 90 remote unit (without central extension possibilities) with analog or digital
inputs / outputs
- An ABB NCSA-01 variable speed drive interface
- A high-speed counter unit
- 30, 50 and 90 series basic units as slave with their own user program
- Or any other device which supports CS31 communication.
Comment:
A connection point fitted solely with digital channels occupies 1 connection point.
A connection point fitted with digital and analog channels occupies 2 connection points of the
available 31.
The maximum number of remote analog units depends on the MASTER basic unit:
- 50 series: - a maximum of 31 remote analog input units
or - a maximum of 31 remote analog output units
or - a maximum of 15 central extensible remote units (ICMK 14 ..) with analog
input/output extensions + 1 remote analog input/output unit (15 x 2 + 1 = 31)
or - a mixed digital/analog configuration within the previous limits
- 90 series: - a maximum of 12 remote analog input units
or - a maximum of 12 remote analog output units
or - a maximum of 12 central extensible remote units with analog extensions
or - a mixed digital/analog configuration within the permissible limits
