1TGE120040R0010 ABB

The configuration of MLink depends on the selected communication protocol to the DCS.

Following communication interface protocols are available:

· PROFIBUS DP (-V0) and PROFIBUS DP-V1

· MODBUS RTU / TCP

· PROFINET IO

MLink contains different software modules depending on its initial configuration. The software

modules are available on request.

Following software modules are available:

· Web Server

· OPC Server (DA & AE)

· Fieldbus

· Time Synchronization

· Redundant Operation

If a specific module is not available on the MLink, please contact your local ABB LVS Sales

organization should this be required.

Web Server

A Web Server can be activated inside MLink. Through network connection web interface

information can be displayed on MView or a PC using web browser software. For details about

Web Interface see the document:

MNS iS Interface Manual Web Interface.

OPC Server

With MNS iS an OPC Server (DA & AE) is available. The software is typically installed on a

server as part of the automation control system. The software installation program is delivered

separately. If activated, the MLink functions as a data provider for the MNS iS OPC Server. For

details about OPC Server see the document:

MNS iS Interface Manual OPC Server.

Fieldbus

MLink can include Fieldbus communication to DCS. The type of Fieldbus must be selected

before ordering the MLink type. The Fieldbus specific information (PROFIBUS, MODBUS etc.)

can be found in the following documents:

MNS iS Interface Manual Profibus

MNS iS Interface Manual Modbus

MNS iS Interface Manual Profinet IO
