DPDT/SPDT
Plug-in blade-style terminals
Retainer clip with sockets
Options: LED, push-to-test and manual override, socket-mounted surge suppressor module, or timer module
Standard ON/OFF flag indicator
Relay faceplate accepts optional Bulletin 1492 snap-in markers
Choice of standard silver/nickel contacts or silver/nickel with gold plated contacts
Maximum duty version available
LED Option: Add suffix (-4) to the selected Bulletin 700-HK relay Cat. No. except for the 240V AC units, add (-4L).
‡ For AgNi Contact with Gold Plating: Replace “3” with “X” in Cat. No. For example, if Cat. No. 700‐HK36A1 is required with Gold Plating, the new catalog number is 700‐HKX6A1.
§ Push‐to‐Test + Manual Override + LED Option: Add suffix (‐3‐4) to the selected 700‐HK Relay catalog number, except for the 240V AC Units, add (‐3‐4L).
♣ For high inductive, Tungsten, or Capacitive load applications, replace the "3" with a "M" in the catalog number. Only available in a SPDT configuration and with 24V DC, 120V AC or 240V AC coil
voltages.
