This chapter gives you an introduction to the AC31 automation, from the overall architecture to
the operational rules of the 40 and 50 series basic units.
The AC31 system consists of the series 30, 40, 50, and 90. This operating manual describes
the series 40 and 50.
The AC31 brings accessibility to beginners and experienced automation users alike, for any
application with 14 to approximately 1000 inputs / outputs and more, using the same set of
basic components.
From a compact machine fitted with a few automated functions to large installations spread over
hundreds of meter, and even kilometers, the AC31 can fit your requirements.
It is therefore possible to realize distributed applications throughout a site, a workshop, or a
machine where each component (input / output units, basic unit) is close to the sensors /
actuators. The whole setup is connected by a single twisted pair over which all information from
the sensors is sent after processing by the basic unit to the actuators via the remote modules.
Additional central units configured as slave can also be connected to this CS31 system bus.
In case of the series 40 and 50 the following communication interfaces are available, to extend
the AC31’s possibilities and integration with the company's other automation systems:
MODBUS, ASCII, ARCNET, RCOM, AF100. The developments in this field are continual.
Many users on all the continents have realized numerous applications such as:
Machine control:
- Manufacturing of floor boards
- Assembly of electrical contactors
- Manufacturing of ceramic products
- Metallic pipe welding, etc.
Controlling-commanding installations:
- Wharf cranes
- Water treatment
- Ski lifts
- Wind power machines, etc.
System management:
- Climatic anagement
- Building power management
- Tunnel ventilation
- Alarms in hospital environments
- Greenhouse lighting / humidity, etc.
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
