Part No. Description Product Life
Cycle Phase
1SAP535100R0001 CP635, control panel, TFT graphical display, single-touch screen, 7”,
800 x 480 pixel, for PB610 applications
Classic
1SAP535100R2001 CP635-B, control panel, TFT graphical display, single-touch screen, 7”,
800 x 480 pixel, for PB610 applications, black front
Classic
1SAP535200R0001 CP635-WEB, control panel, TFT graphical display, single-touch screen,
7”, 800 x 480 pixel, for visualization of AC500 V2.3 web server
Classic
Parameter Value
Display
Size diameter 7”
Resolution 800 x 480 pixels
Type TFT-LCD
Number of colors 65536
Brightness 300 cd/m²
Backlight
Type LED
Lifetime, typical 40 000 h at 25 °C
Touch screen
Type Single-touch,
resistive touch screen, 4 wires
Material glass, covered by plastic film
Design
CP635, CP635-WEB ABB design passepartout
CP635-B Black passepartout
System resources
Processor type ARM Cortex-A8, 600 MHz
Operating system Microsoft Windows 6.0 Core
Application memory For HMI projects of up to 30 MB
RAM 256 MB
Flash 128 MB
Card slot SD card
Data backup Battery
Battery type 3 V, 50 mAH, Lithium, rechargeable, not userreplaceable
Data buffering time at 25 °C Ca. three months
Real-time clock:
Accuracy < 100 ppm at 25 °C
With battery back-up Yes
