Units are supplied factory-assembled
when ordered with contact block.
Product Number and price do not include
nameplate. All nameplates must be
ordered as a separate item.
Suitable for use in NEMA Type 1, 3, 3R, 4,
4X, 12, and 13 applications., when mounted in enclosures rated for those same
applications. For some NEMA Type 4X
applications, protective caps will improve
corrosion resistance.
Release Type Cam Code Configuration Product Number1
Spring Return C R 4 None CR104PSG84B
Spring Return C R 4 1NO-1NC CR104PSG84B91
Spring Return C R 4 2NO-2NC CR104PSG84B92
Spring Return C R 2 None CR104PSG82B
Spring Return C R 2 1NO-1NC CR104PSG82B91
Spring Return C R 2 2NO-2NC CR104PSG82B92
Spring Return C R 3 None CR104PSG83B
Spring Return C R 3 1NO-1NC CR104PSG83B91
Spring Return C R 3 2NO-2NC CR104PSG83B92
Spring Return C R 5 None CR104PSG85B
Spring Return C R 5 2NO-2NC CR104PSG85B92
Spring Return C R 6 None CR104PSG86B
Spring Return C R 6 2NO-2NC CR104PSG86B92
3-Position - Black Knob1 - Spring Return L C R
3 Position Contact
Release Type Cam Code Configuration Product Number1
Contacts viewed from front of panel
Left Right
1 NO-1 NC
Suffix (B91)
NC
NO
2 NO-2 NC
Suffix (B92)
NC
NO
Numbers and letters are molded into blocks at terminals.
Schematic Diagrams - Factory Forms
Knob-Operated Selector Switch Contacts viewed from front of panel.
Spring Return L C R 4 None CR104PSG94B
Spring Return L C R 4 1NO-1NC CR104PSG94B91
Spring Return L C R 4 2NO-2NC CR104PSG94B92
Spring Return L C R 2 None CR104PSG92B
Spring Return L C R 2 1NO-1NC CR104PSG92B91
Spring Return L C R 2 2NO-2NC CR104PSG92B92
Spring Return L C R 3 None CR104PSG93B
Spring Return L C R 3 1NO-1NC CR104PSG93B91
Spring Return L C R 3 2NO-2NC CR104PSG93B92
Spring Return L C R 5 None CR104PSG95B
Spring Return L C R 5 2NO-2NC CR104PSG95B92
Spring Return L C R 6 None CR104PSG96B
Spring Return L C R 6 2NO-2NC CR104PSG96B92
1To order knob in a color other than black, replace the “B” in listed Product Numbers
with E (Yellow), G (Green), L (Blue), or R (Red).
