ABB NTCL01

The NTCL01 provides connectors for both twinaxial cable and

coaxial cable. Jumpers on the circuit board set the impedance

to match the communication cable. The +24 VDC supplied to

the board is fused, protecting the electronic circuitry on board.

This manual has five sections and two appendices.

Introduction Provides an overview of the TCL.

Installation Explains physical installation, wiring and cable requirements,

jumper settings, etc.

Maintenance Contains a maintenance schedule.

Repair/Replacement

Procedures

Explains how to replace the fuse or the module.

Support Services Explains training, documentation and how to order parts from

Bailey Controls.

Appendices Briefly discuss the modules that can use the TCL and provide a

cross-reference of dipswitch and jumper settings for those

modules.

HOW TO USE THIS MANUAL

Read this manual before installing the TCL. Do the installation

steps in order. Do not operate the TCL until you complete all

the steps in this section. Refer to the appendices for specific

module and cable questions.
