The DO815 is a 8 channel 24 V digital output module for the S800 I/O.
The output voltage range is 10 to 30 V and the maximum continuous
output current is 2 A @ 24 V. The outputs are protected against short
circuits, and over load. The outputs are divided into two individually
isolated groups with four output channels in each group. Each
output channel consists of a short circuit and over load protected
high side driver with open load detection (on active signal), EMC
protection components, inductive load suppression, output status
indication LEDs and optical isolation barrier.
8 channels for 24 V d.c. current sourcing outputs
2 isolated groups of 4 channels with under voltage detection
OSP sets outputs to predetermined state upon communication error
Output status indicators and a channel wise error flag
Short-circuit protection to ground and positive supply
Over load protection
Open load and short-circuit detection
Two output fault operation modes: Automatic reset mode and Fault latching mode
Inductive load driving capability
Filament lamp load up to 10W
Environment and certification
CE mark Yes
Electrical safety IEC 61131-2, UL 61010-1, UL 61010-2-201
Hazardous Location C1 Div 2 cULus, C1 Zone 2 cULus, ATEX Zone 2
Marine certification ABS, BV, DNV-GL, LR
Protection rating IP20 according to IEC 60529
Corrosive atmosphere ISA-S71.04 G3
Climatic operating conditions
0 to +55 °C (Storage -40 to +70 °C), RH=5 to 95 % no condensation, IEC/EN
61131-2
Pollution degree Degree 2, IEC 60664-1
Mechanical operating conditions IEC/EN 61131-2
EMC EN 61000-6-4, EN 61000-6-2
Overvoltage categories IEC/EN 60664-1, EN 50178
Equipment class Class I according to IEC 61140; (earth protected)
Max ambient temperature 55 °C (131 °F), for vertical mounting in compact MTU 40 °C (104 °F)
RoHS compliance DIRECTIVE/2011/65/EN (EN 50581:2012)
WEEE compliance DIRECTIVE/2012/19/EU
