The thermistor motor protection relay CM-MSS.41
monitors the winding temperature of motors and
protects them from overheating, overload and
insufficient cooling.
The device is available with two different terminal
versions. You can choose between the proven
screw connection technology (double-chamber
cage connection terminals) and the completely
tool-free Easy Connect Technology (push-in
terminals).
Characteristics
– 1 measuring circuit
– Test / Reset button
– Auto, manual or remote reset configurable
– Short-circuit monitoring of the sensor circuit, configurable
– Dynamic interrupted wire detection
– Non-volatile fault storage, configurable
– Easy configuration via DIP switches
– LEDs to distinguish between different failure causes
– Overvoltage protected supply and measuring inputs
– According to the product standard IEC 60947-8
– Screw connection technology or Easy Connect Technology available
– Housing material for highest fire protection classification UL 94 V-0
– Tool-free mounting on DIN rail as well as demounting
– 22.5 mm (0.89 in) width
– Various certifications and approvals (see overview, document no. 2CDC112248D0201)
– Tool-free connection of rigid and flexible wires with
wire end ferrule
– Easy connection of flexible wires without wire end
ferrule by opening the terminals
– No retightening necessary
– One operation lever for opening both connection
terminals
– For triggering the lever and disconnecting of wires
you can use the same tool (Screwdriver according to
DIN ISO 2380-1 Form A 0.8 x 4 mm (0.0315 x 0.157
in), DIN ISO 8764-1 PZ1 ø 4.5 mm (0.177 in))
– Constant spring force on terminal point independent
of the applied wire type, wire size or ambient
conditions (e. g. vibrations or temperature changes)
– Opening for testing the electrical contacting
– Gas-tight
Double-chamber cage connection terminals
– Terminal spaces for different wire sizes
– One screw for opening and closing of both cages
– Pozidrive screws for pan- or crosshead screwdrivers
according to DIN ISO 2380-1 Form A 0.8 x 4 mm
(0.0315 x 0.157 in), DIN ISO 8764-1 PZ1 ø 4.5 mm
(0.177 in)
