ICMK14F1-J10 1SBP260050R1001 ABB

The ICMK14F1-M and ICMK14N1-M remote units were developed according to the European

EC directives, the main national and international IEC 1131-1 and IEC 1131-2 standards and

the EN61131-2 product standard concerning automation devices.

1 - Location for the DIN rail

 2 - Plate fixture with unit earthing

 3 - Lock for DIN rail mounting

 4 - Location for external dual connector

 5 - Location for the cabling connectors:

- of 24 V d.c. output power for the inputs

 (available only for the remote units with 120 / 230 V a.c. power)

- of the inputs

 6 - Visualization set for the status of the 8 inputs / 6 outputs

 7 - Location of the connector for the connection of input/output extensions

 8 - Location of the cabling connectors:

- for the power supply

- for the outputs

 9 - Location of the addressing rotate selectors (see enlargement)

10 - Unit status visualization area:

- POWER: power on

- RUN: Blinking indicates the valid message received

- ERR: On indicates error(s) present and blinking indicates configuration action
