Brand： ABB
Model number：RDCO-02C
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.35Kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Description:
Operator Functions
Autoscroll When enabled (On), operator pages are scrolled continuously at intervals of 10 seconds per
page.
Soft Key Function Assigns a dedicated function to the Navigation key (right) – see page 6.
Configuration Displays the Access Level enabling selection of configuration levels.
Auto / Manual Toggles between Auto and Manual control modes.
Local / Remote Toggles between Local and Remote setpoint modes.
Scroll View Scrolls through each available Operator view.
Alarm Ack Acknowledges all active unacknowledged alarms.
Toggle Signal Provides source that toggles between 2 states – can be assigned to outputs or used to
select sources.
Edge Signal Provides an edge-triggered source that is active on key press. Can be assigned to outputs
or used to select sources
The selected units are used by the linearizer and displayed in the Operator pages – see
page 23.
Not applicable for Pulse Input, Digital volt-free or 24V Digital parameters – see page 41.
Thermocouple and RTD inputs (see page 41) are restricted to deg C, deg F, Kelvin – see
Appendix 86, page 86 for analog input units.
Eng. Dps Engineering decimal places – selects the resolution (decimal places) displayed for the input
value.
Eng. Low
Eng. High
Specifies the engineering low (minimum) / high (maximum) value.
For example, for an electrical input range of 4.0 to 20.0 mA, representing a pressure range
of 50 to 250 bar (725 to 2630 psi), set the Eng Low value to 50.0 and the Eng High value to
250.0.
Not applicable for Pulse Input, Digital volt-free or 24V Digital parameters – see page 41.
Pulse Units Selects the unit of measure for the pulse input type.
Pulse / Unit Sets the number of pulses required to represent 1 pulse unit (as set above). For example, if
Pulse Units = Kl and Pulse / Unit = 10.00000000, each pulse represents 0.1 Kl, 10 pulses =
1 Kl.
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
