RINT-5514 ABB Feeder Protection and Control

INQUIRE NOW

Products Name: RINT-5514 ABB Feeder Protection and Control

PRODUCT DESCRIPTION

Brand： ABB

Model number：RINT-5514

Colour：new

Warranty: 12 months

Lead Time：3-day working day

Country of origin: USA Price: Please contact us

Product weight：0.33kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

Universal process controllers, 1/8, 1/4 and 1/2 DIN 7 Advanced Level

36 IM/CM/B–EN Rev. U

…Device Setup / …Basic Setup

Loop 1 Split O/P These types of outputs split the Control (PID) output signal (see page 32) into 2 signals. The

linear relationship between the PID output and the 2 outputs can be configured in the

control configuration.

Instrument Tag A 16-character alphanumeric tag, displayed on Operator pages.

Mains Freq Used to set the internal filters to reduce mains power frequency interference.

Config Action The Config Action parameter is used to determine how the controller and controller outputs

behave when the Advanced level is entered – see page 35.

Continue The controller continues to operate as in Operator level. Outputs continue to operate as

normal.

Hold Puts the controller into Manual control mode. When the Configuration level is exited, the

controller returns to the pre-Configuration mode of operation. Digital, relay and analog

outputs are held at their value / state when Configuration mode is entered.

Inactive Puts the controller into Manual control mode. When the Advanced level is exited, the

controller returns to the pre-configuration mode of operation.

Digital and relay outputs are turned off. Analog outputs are set to 0 mA.

Reset to Defaults Resets all configuration parameters to their default values.

ControlMaster CM10, CM30 and CM50

Universal process controllers, 1/8, 1/4 and 1/2 DIN 7 Advanced Level

IM/CM/B–EN Rev. U 37

…Device Setup

Security Setup 2 Security access levels are provided, each protected by a password of up to 6

alphanumeric characters.

Note. Passwords are not set at the factory and must be entered by the end user(s).

Basic Password Basic level provides access to the Basic level – see section 6, page 28.

Advanced Password Provides access to all configuration parameters – see section 5.4, page 27.

Reset Passwords Resets all passwords to factory values
