1492-ASPH3 Allen Bradley Compact™ 16-Point AC/DC Relay Output Module

INQUIRE NOW

Products Name: 1492-ASPH3 Allen Bradley Compact™ 16-Point AC/DC Relay Output Module

PRODUCT DESCRIPTION

Brand:  Allen Bradley

Model number:1492-ASPH3

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.5kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

Locate holes every 17.5 mm (0.689 in.) to allow for a mix of single-wide and

one-and-a-half-wide modules (e.g. 1769-OA16).

Panel Mounting Procedure Using Modules as a Template

The following procedure allows you to use the assembled modules as a template

for drilling holes in the panel. If you have sophisticated panel mounting equipment,

you can use the dimensional template provided on page 6. Due to module

mounting hole tolerance, it is important to follow these procedures:

1. On a clean work surface, assemble no more than three modules.

2. Using the assembled modules as a template, carefully mark the center of all

module-mounting holes on the panel.

3. Return the assembled modules to the clean work surface, including any

previously mounted modules.

4. Drill and tap the mounting holes for the recommended M4 or #8 screw.

5. Place the modules back on the panel, and check for proper hole alignment.

6. Attach the modules to the panel using the mounting screws.

7. Repeat steps 1 to 6 for any remaining modules.

TIP If mounting more modules, mount only the last one of

this group and put the others aside. This reduces

remounting time during drilling and tapping of the next

group
