1761-CBl-AM00 Allen Bradley MicroLogix 1000 Programmable Controllers

INQUIRE NOW

Products Name: 1761-CBl-AM00 Allen Bradley MicroLogix 1000 Programmable Controllers

PRODUCT DESCRIPTION

Brand:  Allen Bradley

Model number:1761-CBl-AM00

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.21kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

Cable lengths of 32 m (105 ft) for plastic cable and 200 m (656.7 ft) for

glass cable are possible for each transmission section (point A to B).

In Figure 3.24, the second Ultra3000-SE system is located in a separate

cabinet and connected with bulkhead adapters.

Figure 3.24

Fiber-Optic Ring Connection (Example 4)

To connect the SERCOS fiber-optic cables:

1. Insert one end of a fiber-optic cable into the Receive SERCOS

connector on the Ultra3000-SE and thread the connector on finger

tight.

2. Insert the other end of the cable (from step 1) into the Transmit

SERCOS connector on the ControlLogix module/SoftLogix PCI

Card and thread the connector on finger tight.

3. Insert one end of another fiber-optic cable into the Transmit

SERCOS connector on the last Ultra3000-SE drive in the ring and

thread the connector on finger tight.

IMPORTANT To avoid signal loss, do not mix glass and plastic

cables when connecting to a bulkhead adapter. Use

glass-to-glass or plastic-to-plastic cable on both sides

of the adapter.

IMPORTANT Clean the fiber-optic cable connectors prior to

installation. Dust in the connectors can reduce signal

strength. For more information, refer to Fiber Optic

Cable Installation and Handling Instructions

(publication 2090-IN010x-EN-P).

This chapter provides a description of maintenance and

troubleshooting activities for the Ultra3000. This chapter includes

these sections:

• Safety Precautions

• General Troubleshooting

• Troubleshooting for SERCOS Drives

• Troubleshooting for DeviceNet Drives

For power-up procedures and system integration with Ultraware or

ControlLogix and SoftLogix modules/PCI cards (see table below) refer

to the Ultra3000 Digital Servo Drives Integration Manual (publication

2098-IN005x-EN-P). Manuals are available electronically (as a .pdf) or

in hardcopy from www.theautomationbookstore.com.
