Brand： Allen Bradley
Model number： 1761-NET-AIC
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：1.01kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Description:
Voiding of CE Compliance
The three-phase and neutral in-line filter applications described above
may not be adequate from an EMC aspect for CE compliance.
Therefore, EMC validity and CE marking by Rockwell Automation is
voided when three-phase and neutral in line filters are used.
Ground Grid or
Power Distribution Ground
Ultra3000 (System A)
Single-Phase AC Input
TB1 Terminals
Ultra3000 (System B)
Single-Phase AC Input
TB1 Terminals
Ultra3000 (System C)
Single-Phase AC Input
TB1 Terminals
Grounded Neutral
Grounded Neutral
The three-phase isolation transformer and neutral
in-line filter applications described in this document
have not been tested for EMC by Rockwell
Automation, and products used in such installations
are not considered CE marked by Rockwell
Automation.
If this three-phase isolation transformer and neutral
in-line filter application is used, the responsibility for
EMC validation lies with the user and CE marking of
the system becomes the user's responsibility.
If CE compliance is a customer requirement,
single-phase line filters which have been tested by
Rockwell and specified for the product should be
used. Refer to AC Line Filters on page C-3 for catalog
numbers.
Publication 2098-IN003E-EN-P — April 2004
Connecting Your Ultra3000 3-9
Grounding Your Ultra3000 All equipment and components of a machine or process system
should have a common earth ground point connected to their chassis.
A grounded system provides a safety ground path for short circuit
protection. Grounding your modules and panels minimize shock
hazard to personnel and damage to equipment caused by short
circuits, transient overvoltages, and accidental connection of
energized conductors to the equipment chassis. For CE grounding
requirements, refer to Meeting CE Requirements in Chapter 1.
Grounding Your System to the Subpanel
Figure 3.9
Chassis Ground Configuration (Multiple Ultra3000 Systems on One Panel)
IMPORTANT To improve the bond between the Ultra3000 and
subpanel, construct your subpanel out of zinc plated
(paint-free) steel.
The National Electrical Code contains grounding
requirements, conventions, and definitions. Follow
all applicable local codes and regulations to safely
ground your system. Refer to the illustration below
for details on grounding your Ultra3000. Refer to
Appendix B for the power wiring diagram for your
Ultra3000 drive.
