1783-BMS20CGP ALLEN BRADLEY

Wire size,

ground

connection

2.5 mm2

 (14 AWG) copper wire suitable for 86 °C (187 °F) above surrounding ambient temperature outside the enclosure, with a suitable ring terminal

Attribute 1783-LMS5 1783-LMS8

Power input 12…24V DC, 0.3…0.2 A(SELV) 12…24V DC, 0.4…0.2 A (SELV)

Power consumption 4.2 W 5.3 W

Power dissipation 4.2 W 5.3 W

Wire size, Ethernet connection(1)

(1) See page 87 for recommended products.

RJ45 connector according to IEC 60603-7, 2 or 4 pair Category 5e minimum cable according to TIA 568-B.1 or Category 5 cable

according to ISO/IEC 24702

Wire size, DC power connection 1.3…0.82 mm2

 (16…18 AWG) solid or stranded copper wire rated at 30 °C (86 °F), or greater, above the surrounding air temperature

Wire size, ground connection 5.2...3.3 mm2

 (10...12 AWG) solid or stranded copper wire

Torque, power terminal screw 0.19 N•m (1.7 in•lb)

Torque, functional ground lug screw 0.51 N•m (4.5 in•lb)

Wiring category

(2)(3)

(2) Use this conductor category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1..

(3) Use this Conductor Category information for planning conductor routing as described in the Stratux 2500 Managed Switches Installation Instructions, publication 1783-IN011.

2 - on power ports

2 - on communication ports

Enclosure type rating None (open-style)

North American temp code T4

ATEX temp code T4
