1786-RPFM A-B Analog output module

INQUIRE NOW

Products Name: 1786-RPFM A-B Analog output module

PRODUCT DESCRIPTION

Brand:  Allen Bradley

Model number:1786-RPFM

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.4kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

Follow these steps to mount a module.

1.Position the module on the 35 x 7.5 mm (1.4 x 0.3 in.) DIN

rail (Allen-Bradley part number 199-DR1) at a 30

2.Hook the lip on the rear of the module onto the top of the

DIN rail, and rotate the repeater module onto the rail.

3. Attach the Vin + wire to one of the Vin + terminals on the RTB.

4. Tighten the screws to 0.6…0.8 N•m (5…7 lb•in).

5. Attach the V

in - wire to one of the V

in - terminals on the RTB.

6. Tighten the screws to 0.6…0.8 N•m (5…7 lb•in).

7. Install the RTB onto the repeater adapter module.

8. Tighten the screws to 0.6…0.8 N•m (5…7 in•lb).

9. Connect the repeater adapter module to the ControlNet network by connecting the drop line of the coax tap to the BNC

connector.

If the adapter has dual ports, connect both ports.

10.Terminate any unused coax ports by connecting a 75  terminator to the unused BNC connector.

One 75  terminator is shipped with the repeater adapter module.

Connect a 1786-RPCD Dual Copper Repeater Module

If you connect only one coax channel on the 1786-RPCD module, you can use either channel 1 or channel 2. Both channels

1 and 2 operate identically and can be used interchangeably. Be sure to terminate the unused channel with a 75 

terminating resistor (catalog number 1786-XT).

1. Connect the ControlNet tap to port #1.

2. Align the knob of the BNC cable connector with the locks of the BNC module connector, and insert the connector into

channel 1.

1786-RPFM   A-B  Analog output module

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
