1797-IB16 Allen Bradley Digital Input Module

INQUIRE NOW

Products Name: 1797-IB16 Allen Bradley Digital Input Module

PRODUCT DESCRIPTION

Brand:  Allen Bradley

Model number:1797-IB16

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.23kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

Mounting the Analog Modules on the Terminal Base Unit

The analog input and output modules mount on a 1797-TB3 or TB3S

intrinsically safe terminal base unit.

1. Rotate keyswitch (1) on terminal base unit (2) clockwise to position 3 for

the 1797-IE8 or -IE8NF or position 4 for the 1797-OE8 as required for

each type of module. Do not change the position of the keyswitch

after wiring the terminal base unit.

2. Make certain the flexbus connector (3) is pushed all the way to the left

to connect with the neighboring terminal base/adapter. You cannot

install the module unless the connector is fully extended.

3. Make sure the pins on the bottom of the module are straight so they will

align properly with the connector in the terminal base unit.

4. Position the module (4) with its alignment bar (5) aligned with the

groove (6) on the terminal base.

5. Press firmly and evenly to seat the module in the terminal base unit.

The module is seated when the latching mechanism (7) is locked into

the module.

6. Make certain that you only connect terminal base units to other

intrinsically safe system modules or adapters to maintain the integrity of

the intrinsically-safe backplane.

7. Remove cap plug (8) and attach another intrinsically safe terminal base

unit to the right of this terminal base unit if required. Make sure the last

terminal base has the cap plug (8) in place.

1797-IB16  Allen Bradley  Digital Input Module

1797-IB16  Allen Bradley  Digital Input Module
